All-terrain truck crane
Chassis 5 bridge number
7-section boom
130 tons lifting capacity
The overall vehicle layout is more compact and rational, and the design of key structural components is further optimized.The innovative five-axle all-terrain chassis design, hydro-pneumatic suspension, and all-wheel steering provide more reliable chassis performance and improved passability.The vehicle utilizes a single-engine mechanical transmission with an independent main oil pump and hydraulic tank system, ensuring high reliability and eliminating the risk of emissions upgrades.
Through the human-machine interface, customers can customize the vehicle's handling based on their personal preferences and usage conditions, meeting their individual needs. The vehicle utilizes hydro-pneumatic suspension technology, adapting to harsh road conditions, providing superior maneuverability and a more comfortable ride. The streamlined, full-width cab and adjustable panoramic sunroof provide a wider field of view and more comfortable operation.
Equipped with an anti-rollover warning system, the system provides early warnings through audio and visual indicators, ensuring safe operation. A voice alarm system provides voice prompts for various actions, preventing misoperation and alerting nearby personnel, ensuring both vehicle operation and personnel safety.
The electric proportional pump with variable displacement and speed control can save 20% of energy. The dual-pump combined/diverged intelligent speed control technology can meet various motion combinations and achieve high efficiency and energy conservation. GCP system.
Specifications:
| Year | Model | Type | Chassis engine | Rated total lifting capacity | Maximum rated engine power | Counter weight | Main boom | Hook | Dimension |
| 2020 | SAC1300T | Truck crane | Weichai | 130 tons | 338 KW | 50.5 tons | 73m | 2 | 15530*2800*4000mm |
